Building Scalable Microservices Architecture with Node.js

Table of Contents

1. Introduction
2. Architecture Overview
3. Service Design Patterns
4. Communication Patterns
5. Data Management
6. Service Discovery & Load Balancing
7. Monitoring & Observability
8. Deployment & Orchestration
9. Security Considerations
10. Best Practices & Pitfalls

Introduction

Microservices architecture has become the standard for building large-scale applications. This guide will show you how to design, implement, and deploy a production-ready microservices architecture using Node.js.

Architecture Overview

Project Structure

microservices-architecture/
├── services/
│   ├── api-gateway/
│   ├── auth-service/
│   ├── user-service/
│   ├── order-service/
│   └── notification-service/
├── shared/
│   ├── proto/
│   ├── events/
│   └── utils/
└── infrastructure/
    ├── kubernetes/
    ├── terraform/
    └── monitoring/

API Gateway Implementation

// services/api-gateway/src/server.ts
import express from "express";
import { createProxyMiddleware } from "http-proxy-middleware";
import { discovery } from "./service-discovery";
import { rateLimit } from "./middleware/rate-limit";
import { authenticate } from "./middleware/auth";

const app = express();

// Service routes configuration
const serviceRoutes = {
  "/auth": "auth-service",
  "/users": "user-service",
  "/orders": "order-service",
};

// Dynamic service discovery and routing
Object.entries(serviceRoutes).forEach(([path, serviceName]) => {
  const proxy = createProxyMiddleware({
    target: discovery.getServiceUrl(serviceName),
    changeOrigin: true,
    pathRewrite: { [`^${path}`]: "" },
    router: async () => discovery.getServiceUrl(serviceName),
  });

  app.use(path, rateLimit, authenticate, proxy);
});

// Health check endpoint
app.get("/health", (req, res) => {
  res.json({
    status: "healthy",
    services: discovery.getHealthStatus(),
  });
});

Service Design Patterns

Event-Driven Architecture

// shared/events/event-bus.ts
import { Kafka } from "kafkajs";
import { EventEmitter } from "events";

export class EventBus {
  private kafka: Kafka;
  private localEmitter: EventEmitter;

  constructor() {
    this.kafka = new Kafka({
      clientId: "my-app",
      brokers: process.env.KAFKA_BROKERS.split(","),
    });
    this.localEmitter = new EventEmitter();
  }

  async publish(topic: string, message: any) {
    const producer = this.kafka.producer();
    await producer.connect();

    await producer.send({
      topic,
      messages: [{ value: JSON.stringify(message) }],
    });

    await producer.disconnect();
    this.localEmitter.emit(topic, message);
  }

  async subscribe(topic: string, handler: (message: any) => Promise<void>) {
    const consumer = this.kafka.consumer({ groupId: "my-group" });
    await consumer.connect();
    await consumer.subscribe({ topic });

    await consumer.run({
      eachMessage: async ({ message }) => {
        const value = JSON.parse(message.value.toString());
        await handler(value);
      },
    });

    this.localEmitter.on(topic, handler);
  }
}

Circuit Breaker Pattern

// shared/utils/circuit-breaker.ts
interface CircuitBreakerOptions {
  timeout: number;
  failureThreshold: number;
  resetTimeout: number;
}

export class CircuitBreaker {
  private state: "CLOSED" | "OPEN" | "HALF_OPEN" = "CLOSED";
  private failureCount: number = 0;
  private lastFailureTime: number = 0;
  private readonly options: CircuitBreakerOptions;

  constructor(options: CircuitBreakerOptions) {
    this.options = options;
  }

  async execute<T>(
    operation: () => Promise<T>,
    fallback?: () => Promise<T>
  ): Promise<T> {
    if (this.state === "OPEN") {
      if (Date.now() - this.lastFailureTime >= this.options.resetTimeout) {
        this.state = "HALF_OPEN";
      } else if (fallback) {
        return fallback();
      } else {
        throw new Error("Circuit breaker is OPEN");
      }
    }

    try {
      const result = await Promise.race([
        operation(),
        new Promise((_, reject) =>
          setTimeout(
            () => reject(new Error("Operation timeout")),
            this.options.timeout
          )
        ),
      ]);

      this.onSuccess();
      return result as T;
    } catch (error) {
      this.onFailure();
      if (fallback) return fallback();
      throw error;
    }
  }

  private onSuccess() {
    this.failureCount = 0;
    this.state = "CLOSED";
  }

  private onFailure() {
    this.failureCount++;
    this.lastFailureTime = Date.now();

    if (
      this.state === "HALF_OPEN" ||
      this.failureCount >= this.options.failureThreshold
    ) {
      this.state = "OPEN";
    }
  }
}

Communication Patterns

gRPC Service Definition

// shared/proto/user-service.proto
syntax = "proto3";

package userservice;

service UserService {
  rpc GetUser (GetUserRequest) returns (User);
  rpc CreateUser (CreateUserRequest) returns (User);
  rpc UpdateUser (UpdateUserRequest) returns (User);
  rpc DeleteUser (DeleteUserRequest) returns (Empty);
}

message User {
  string id = 1;
  string email = 2;
  string name = 3;
  string role = 4;
  string created_at = 5;
}

message GetUserRequest {
  string id = 1;
}

message CreateUserRequest {
  string email = 1;
  string name = 2;
  string password = 3;
}

message UpdateUserRequest {
  string id = 1;
  optional string email = 2;
  optional string name = 3;
}

message DeleteUserRequest {
  string id = 1;
}

message Empty {}

gRPC Service Implementation

// services/user-service/src/grpc-server.ts
import * as grpc from "@grpc/grpc-js";
import * as protoLoader from "@grpc/proto-loader";
import { UserService } from "./services/user.service";
import { ProtoGrpcType } from "./proto/user-service";

const packageDefinition = protoLoader.loadSync("./proto/user-service.proto");
const proto = grpc.loadPackageDefinition(
  packageDefinition
) as unknown as ProtoGrpcType;

const server = new grpc.Server();
const userService = new UserService();

server.addService(proto.userservice.UserService.service, {
  getUser: async (call, callback) => {
    try {
      const user = await userService.getUser(call.request.id);
      callback(null, user);
    } catch (error) {
      callback(error as grpc.ServiceError);
    }
  },

  createUser: async (call, callback) => {
    try {
      const user = await userService.createUser(call.request);
      callback(null, user);
    } catch (error) {
      callback(error as grpc.ServiceError);
    }
  },

  // ... other methods
});

server.bindAsync(
  `0.0.0.0:${process.env.GRPC_PORT}`,
  grpc.ServerCredentials.createInsecure(),
  (error, port) => {
    if (error) {
      console.error(error);
      return;
    }
    server.start();
    console.log(`gRPC server running on port ${port}`);
  }
);

Data Management

Database Per Service Pattern

// services/order-service/src/config/database.ts
import { Pool } from "pg";
import { Prisma, PrismaClient } from "@prisma/client";

export class Database {
  private static instance: Database;
  private prisma: PrismaClient;
  private pool: Pool;

  private constructor() {
    this.prisma = new PrismaClient({
      log: ["query", "info", "warn", "error"],
    });

    this.pool = new Pool({
      user: process.env.DB_USER,
      password: process.env.DB_PASSWORD,
      host: process.env.DB_HOST,
      port: parseInt(process.env.DB_PORT),
      database: process.env.DB_NAME,
    });
  }

  static getInstance(): Database {
    if (!Database.instance) {
      Database.instance = new Database();
    }
    return Database.instance;
  }

  async transaction<T>(
    callback: (prisma: Prisma.TransactionClient) => Promise<T>
  ): Promise<T> {
    return this.prisma.$transaction(callback);
  }

  async query(text: string, params?: any[]) {
    return this.pool.query(text, params);
  }

  async disconnect() {
    await this.prisma.$disconnect();
    await this.pool.end();
  }
}

Service Discovery & Load Balancing

Service Discovery with Consul

// shared/utils/service-discovery.ts
import Consul from "consul";

export class ServiceDiscovery {
  private consul: Consul.Consul;
  private cache: Map<string, string[]> = new Map();
  private readonly ttl = 60000; // 1 minute cache

  constructor() {
    this.consul = new Consul({
      host: process.env.CONSUL_HOST,
      port: process.env.CONSUL_PORT,
    });
  }

  async register(
    serviceName: string,
    address: string,
    port: number
  ): Promise<void> {
    await this.consul.agent.service.register({
      name: serviceName,
      address,
      port,
      check: {
        http: `http://${address}:${port}/health`,
        interval: "10s",
        timeout: "5s",
      },
    });
  }

  async discover(serviceName: string): Promise<string[]> {
    const cached = this.cache.get(serviceName);
    const now = Date.now();

    if (cached && now - cached.timestamp < this.ttl) {
      return cached.addresses;
    }

    const { services } = await this.consul.catalog.service.nodes(serviceName);
    const addresses = services.map(
      (service) => `${service.ServiceAddress}:${service.ServicePort}`
    );

    this.cache.set(serviceName, {
      addresses,
      timestamp: now,
    });

    return addresses;
  }

  async deregister(serviceId: string): Promise<void> {
    await this.consul.agent.service.deregister(serviceId);
  }
}

Monitoring & Observability

Distributed Tracing

// shared/utils/tracer.ts
import { trace, context } from "@opentelemetry/api";
import { Resource } from "@opentelemetry/resources";
import { SemanticResourceAttributes } from "@opentelemetry/semantic-conventions";
import { NodeTracerProvider } from "@opentelemetry/sdk-trace-node";
import { SimpleSpanProcessor } from "@opentelemetry/sdk-trace-base";
import { JaegerExporter } from "@opentelemetry/exporter-jaeger";

export class Tracer {
  static init(serviceName: string) {
    const provider = new NodeTracerProvider({
      resource: new Resource({
        [SemanticResourceAttributes.SERVICE_NAME]: serviceName,
      }),
    });

    const exporter = new JaegerExporter({
      endpoint: process.env.JAEGER_ENDPOINT,
    });

    provider.addSpanProcessor(new SimpleSpanProcessor(exporter));
    provider.register();

    return trace.getTracer(serviceName);
  }

  static async withSpan<T>(
    name: string,
    fn: () => Promise<T>,
    attributes?: Record<string, string>
  ): Promise<T> {
    const span = trace.getTracer("default").startSpan(name);

    if (attributes) {
      span.setAttributes(attributes);
    }

    try {
      const result = await context.with(
        trace.setSpan(context.active(), span),
        fn
      );
      span.end();
      return result;
    } catch (error) {
      span.recordException(error);
      span.end();
      throw error;
    }
  }
}

Deployment & Orchestration

Kubernetes Configuration

# infrastructure/kubernetes/user-service.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: user-service
spec:
  replicas: 3
  selector:
    matchLabels:
      app: user-service
  template:
    metadata:
      labels:
        app: user-service
    spec:
      containers:
        - name: user-service
          image: user-service:latest
          ports:
            - containerPort: 3000
          env:
            - name: NODE_ENV
              value: "production"
            - name: DB_HOST
              valueFrom:
                secretKeyRef:
                  name: db-secrets
                  key: host
          resources:
            limits:
              cpu: "1"
              memory: "1Gi"
            requests:
              cpu: "500m"
              memory: "512Mi"
          livenessProbe:
            httpGet:
              path: /health
              port: 3000
            initialDelaySeconds: 30
            periodSeconds: 10
          readinessProbe:
            httpGet:
              path: /health
              port: 3000
            initialDelaySeconds: 5
            periodSeconds: 5
---
apiVersion: v1
kind: Service
metadata:
  name: user-service
spec:
  selector:
    app: user-service
  ports:
    - port: 80
      targetPort: 3000
  type: ClusterIP

Security Considerations

Service-to-Service Authentication

// shared/utils/service-auth.ts
import jwt from "jsonwebtoken";
import { promisify } from "util";

export class ServiceAuth {
  private static instance: ServiceAuth;
  private readonly secretKey: string;

  private constructor() {
    this.secretKey = process.env.SERVICE_AUTH_SECRET;
  }

  static getInstance(): ServiceAuth {
    if (!ServiceAuth.instance) {
      ServiceAuth.instance = new ServiceAuth();
    }
    return ServiceAuth.instance;
  }

  async generateToken(serviceName: string): Promise<string> {
    return jwt.sign(
      {
        service: serviceName,
        iat: Math.floor(Date.now() / 1000),
      },
      this.secretKey,
      { expiresIn: "1h" }
    );
  }

  async verifyToken(token: string): Promise<boolean> {
    try {
      await promisify(jwt.verify)(token, this.secretKey);
      return true;
    } catch {
      return false;
    }
  }
}

Best Practices & Pitfalls

Key Considerations

1. Service Boundaries

   • Keep services focused and cohesive
   • Define clear domain boundaries
   • Avoid shared databases

2. Data Consistency

   • Implement Saga pattern for distributed transactions
   • Use event sourcing when appropriate
   • Handle eventual consistency

3. Resilience

   • Implement circuit breakers
   • Use timeouts and retries
   • Plan for failure

4. Monitoring

   • Implement comprehensive logging
   • Use distributed tracing
   • Monitor service health

5. Security

   • Implement service-to-service authentication
   • Use TLS for all communications
   • Regular security audits

Conclusion

Building a microservices architecture requires careful planning and consideration of many factors. This guide provides a solid foundation for building scalable, resilient, and maintainable microservices using Node.js.

Additional Resources

• Microservices Pattern
• The Twelve-Factor App
• Kubernetes Documentation
• OpenTelemetry Documentation
